TWR LED Obstruction Lighting
LED OL2 FAA Type L-810 - 120-240 VAC
FAA Type L-810 Red LED Double Obstruction Light with Valox™ Base
Key Features
-
5-Year Limited Warranty
-
96% Reduced energy consumption versus incandescent
-
Aviation clear Acrylic Fresnel lens
-
No special tools required for installation or maintenance
-
Valox™ base, stainless steel latches and hardware for corrosion protection
-
Neoprene gasket for weather proofing
Specs
-
Intensity: Low
-
Lamp Description: LED
-
Horizontal Coverage: 360°
-
Vertical Beam: 10° Minimum
-
Effective Candelas (Night): 32.5 Minimum +/- 20%
-
Flash Head Height: 12" (30.88 cm)
-
Flash Head Diameter: 13.5" (34.29 cm)
-
Flash Head Lens Material: Fresnel Acrylic
-
Flash Head Base Material: Valox™ (Red)
-
Weight: 5.52 lbs (2.503 kg)
-
Hub Sizes: 0.75"(1" or 1.25" with enlarger)
-
Wind Load: CAAA = 0.2 ft sq
-
Operating Temperature: -55°C to +55°C
-
Lamp Current: 0.12 Amps
-
Power Requirements: 120V - 240V AC, 50/60 Hz
(Also Available in 12V - 24V, & 48V DC)
